24-Port 10/100/1000M 60W POE++ Injector

Ethernet

Standards:

IEEE 802.3 10Base-T Ethernet

IEEE 802.3u 100Base-TX Fast Ethernet

IEEE 802.3ab 1000Base-T Gigabit Ethernet

Processing Type:

Forward

Half-duplex, Full-duplex

Forward Filter Rate:

1,488,000pps (1000Mbps)

Cabling:

10/100/1000Base-T: Cat5 or above

Maximum Distance:

Ultra PoE (60W): 4-pair UTP Cat. 5, 5e, 6 up to 100m (328ft)

802.3af / at PoE (15W / 30W): 2-pair UTP Cat. 3, 4, 5, up to 100m (328ft)

Connector:

LAN: 24 x RJ-45 STP, “Data” Input Port

POE: 24 x RJ-45 STP, “Data + Power” Output Port

AC Connector: 1 x AC Input power socket, IEC-60320 C13

Environmental

Operating Temperature:

-10°C to 50°C (14°F to 122°F)

Storage Temperature:

-20°C to 70°C (-4°F to 158°F)

Relative Humidity:

5% to 95% non-condensing

MTBF:

>200,000hrs

Electrical and Mechanical

Input Voltage Range:

100-240V AC @50/60Hz

Output Voltage:

52VDC

PoE (Power over Ethernet)

Standard:

IEEE 802.3af

IEEE 802.3at

Port:

RJ45

Power Pin Assignment

V+(Pin1,2)V-(Pin3,4)or V+(Pin4,5)V-(Pin7,8)

PoE Working Mode

Auto-detection of receiving end

Auto-management of power

PoE Power

1200W

LED Indicators

Power:

Power Status

PoE:

PoE Output Status

Dimensions (W×D×H):

440 x 235 x 43mm

Weight:

7.0Kg

Casing:

Metal Case

Mounting Options:

19inch Rackmount

Regulatory Approvals

ISO9001

FCC part 15, Class A

EN55022:2006+A1: 2007 Class A

Surge Protection:

RJ45: 1KV

Power: 500W

ESD: 4KV/8KV
